4mm Syringe Filter
Products
Click image to view full sizeItem-Name:
Specification:
4mm Syringe Filter
Specification:4mm Syringe Filter
Housing: Virgin medical grade polypropylene (PP)
Filtration Area: 0.06cm²
Inlet: Female luer-lock
Outlet: Male luer-slip
Packaging: 200 pcs/pk
More-Details:
◆ More Details:
► Color coded for easy identifications
► With luer lock inlet for a more secure fit
► Medical grade polypropylene housing
► Compatible with various chemicals
► Orders can be customized to your requirements
► Multiple membranes to choose from
► Low adsorption of analytes
► OEM accepted
Specifications | |
| Housing Material | Medical grade PP |
| Membrane Diameter | 4mm |
| Filtration Area | 0.06cm² |
| Process Volume | 1 mL |
| Highest Temp | 45℃ |
◆ Order information
1 Membrane | 2 Diameter | 3 Sterile | 4 Pore Size | 5 Membrane Characteristics | |
PVDF PTFE Nylon MCE | CA PES RC GF | X04=4mm 017=17mm 033=33mm | N (Non-Sterile) | 020=0.20um 022=0.22um 045=0.45um 100=1.0um 300=3.0um 500=5.0um | I = Hydrophilic O = Hydrophobic |
Example：PTFE 017 N 045 I = 17mm Syringe Filter, Hydrophilic PTFE 0.45um, color coded
◆ Syringe Filter Chemical Compatibility of Membranes
Please refer to the Chemical Compatibility Table.
◆ Patents-Syringe Filters Features
 |  |  |
